| Brand | Switch Electronics |
|---|---|
| Contact Configuration | SPDT |
| Current Rating | 3A |
| Unit Quantity | 5 |
| Current Type | AC/DC |
| Maximum Amperage | 3A |
| Country of Origin | China |
| Application | Electronics |
| Termination Type | Quick Connect |
| Number of Positions | 2 |
| IP Rating | IP67 |
| Electrical Connection | Quick Connect |
| Coil Voltage | 250VAC |
| EAN | 5063200001166 |
Check the listing for details. 5 x Push Button Waterproof Microswitch SPDT 3A Micro Switch. Condition: New, Made in China. Listed at 24.22 USD. 5 x Push Button Waterproof Microswitch SPDT 3A Micro Switch 5 x Push Button Waterproof Microswitch SPDT 3A Micro Switch £ 8.39 Ask a question Miniature microswitch featuring a push button actuator, housed in a waterproof compact package capable of switching up to 3A. The switch features quick connect terminals and is suitable for domestic and industrial applications. Pack size: 5 Push button actuator Rating: 3A 250VAC / 48VDC NO / NC contacts 2.8mm quick connect terminals Operating force: 300gf max Release force: 70gf min Pre-travel: 1.2mm max Over-travel 0.6mm min Differential travel: 0.2mm max Body dimensions: 19.9 x 6.4 x 9.3mm (Length x Width x Height) About Us Shop related items eBay & Ecommerce Stores By.
