Check the listing for details. Bionet 12 Channel Interpretive Resting ECG w/ Spirometer Cardio7-S. Condition: New. Listed at 2830.00 USD. Bionet 12 Channel Interpretive Resting ECG with Spirometer Cardio 7-S The Cardio7 is a reliable, interpretive, resting ECG with spirometer. It features a large 7” TFT LCD touch screen with WiFi. It supports USB flash drive, a QWERTY keyboard, JPEG/PDF file format, one channel long-term recording, and storage of up to 200 ECGs and PFT tests. It stores and shows the recent 5-minute full channel ECG in order to print out the missed abnormal ECG waveforms. It prints in multiple formats, including 12/6/3 channel ECG reports and FVC/SVC/MVV pulmonary test reports. It can be connected to PACS server through DICOM 3.0 and send the ECG and spirometer test reports to the server. Cardio7 stands out for its advanced technology, high functionality, ease of use, and an unbeatable price/performance ratio.Maximized Ease of UseCardio7 combines menu-guided touch screen technology with a convenient rotary key and buttons to maximize ease of use. USB barcode reader and keyboard can be attached through USB ports.Built-In Memory and Supports USB Flash DriveStore up to 200 ECGs in internal flash memory and the saved ECGs can be converted to various standard file formats like JPG, PDF, XML, MFER and DCM and exported to external USB flash drive.EMR supportThe Cardio7-S sends ECGs to PC by using BMS-Plus windows based PC software through LAN or WiFi. It supports DICOM 3.0 protocol to retrieve work lists from PACS and save ECG images to PACS. USB flash drive can be used to move ECGs stored in Cardio7 to PC.Clinically Important Simultaneous 12 Lead AcquisitionCardio7-S acquires 10 full seconds of ECG data simultaneously from 10 leads to produce an accurate 12 channel printout with analysis.Pulmonary Function TestCardio7-S provides the pulmonary function tests including FVC (Forced Vital Capacity), SVC (Slow Vital Capacity), and MVV (Maximum Voluntary Maximum). Pre-post bronchodilator comparison is supported. With disposable mouthpiece, no cleaning and sterilization are needed.Full Disclosure FunctionCardio7-S stores and shows the recent 5-minute full channel ECG in order to print out the missed abnormal ECG waveforms.Enhanced InterpretationThe ECG printout offers detailed interpretation information in text/guide/vector report format to aid in diagnosis. Provides 12 channel, 6 channel + 1 rhythm, 3 channel + 1 rhythm, and 3 channel + 3 rhythm report. Supports pediatric interpretation.Long-term Recording & Automatic Arrhythmia DetectionCardio7 provides one channel long-term recording like 1, 3, 5, 10 minutes with arrhythmia detection and HRV (Heart Rate Variability) analysis. A4 Full Size PaperCardio7-S produces full size A4 printouts in 1, 3, 6 and 12 channel formats and FVC/SVC/MVV test formats. Full size print-outs improve readability and make it easier for filing in the patient chart. BMS-Plus is a software program that enables you to interface Cardio7-S to Windows based computers through LAN or WiFi. The ECG and PFT data from Cardio7-S is saved in either Bionet’s proprietary file format or JPEG or PDF. The JPEG file format ensures compatibility with most EMR packages. BMS-Plus displays real-time ECG data on-screen, instantly performs a full set of measurements and offers diagnostic aid. In addition, BMS-Plus can eliminate the need for costly thermal paper by printing a variety of comprehensive reports on standard printer/copier paper.Includes:Cardio7 Main Unit, 10 Lead ECG Patient Cable, Alligator Clips, Electrodes, Spirometer Sensor, Disposable Mouthpieces, Nose Clip, Medi-Graph Paper, Hospital Grade Power Cord, Operation Manual, Diagnostics Guide Book, USB Flash Drive with BMS-Plus Software Installed, USB WiFi Dongle, Rechargeable Battery, and a 4-Year Warranty Card. Specifications:ECG leads12 channel simultaneous ECG and acquisitionDimension300 (w) x 299 (h) x 123 (d) mm Approximately 4 kgRecordAuto, Rhythm, Disclosure, Arrhythmia DetectRecording channel3 channels + 1 rhythm, 3 channels + 3 rhythm, 6 channels + 1 rhythm, 12 channels, 1 channel long time (1 min, 3 min, 5 min, 10 min) and special reports (text, guide, vector)Sensitivity2.5, 5, 10, 20, auto (I~aVF: 10, V1~V6: 5) mm/mVPrinting speed5, 12.5, 25, 50, 100 mm/sSampling rate2,000 samples per secondFiltersAC (50/60Hz, - 20dB or better)Muscle (25~35Hz, -3dB or better)Base line drift (0.05, 0.1, 0.2 Hz, -3dB or better)Low pass filter: off, 40Hz, 100Hz, 150 HzDisplay7" color TFT wide display (800 x 480)Monitor DisplayHR, ID, date, AC or battery state, sensitivity, speed, number of saved data, printing form, rhythm leadUser InterfaceTouch screen, hot key, barcode scanner, USB keyboardPatient dataID, name, age, sex, height, weight, smoke, raceBasic measurementHeart rate, PR, QRS, QT/QTc, P-R-T axisRecorderThermal print head, thermal roll paperReport papers: (width x length)- A4: 215 mm (8.5") x 297 mm (11.7")- Letter: 215 mm (8.5") x 280 mm (11") Resolution:- Vertical: 8 dot/mm- Horizontal: 16 dot/mmElectricalInternal noise : 20uV (p-p )maxInput impedance : More than 50M?Input voltage range : ±5mVCMRR : +105dBDC offset voltage : >= ±400mVPatient leakage current: < 10 uAFrequency response 0.05~150Hz within -3 dbIsolated, defibrillation and ESU protectedSignal quality controlPacemaker pulse detection lead fault detection, signal saturation detection.ECG data storageInternal storage for 200 ECGs and external USB flash drivePowerInput: 100-240 VAC, 2-1 A, 50/60 HzOutput: 60 VA maxExternal linkLAN, 2 USB PortFile formatPDF, JPG, XML, MFER, DCMBatteryType: Replaceable and rechargeable Lithium IonCapacity: 6 hours of continuous operation without printing or Approx. 3 hours of 200 ECG printoutsCommunicationRS232, LAN, WiFi, USB flash drive, USB barcode scannerSafety conformityClass 1, Type CF, CE, FDA, KFDA, CFDA, NCCEnvironmentOperating humidity: 30~85%Operating temperature: 10° ~ 40° CStandard accessoryPower Cord (1 ea.), Patient Cable (1 ea.), ECG clips (1 set), Disposable Electrodes (1 pouch), Chart paper (1 ea.), Operation manual (1 ea.), Diagnose guide (1 ea), Rechargeable battery (1 ea), USB WiFi dongle (1 ea) OptionsCart, HAnger, DICOM 3.0* Specifications can be changed without prior notification. SPIROMETER SpecsDimension47 (W) x 200 (H) x 34 (D)mm, approx. 250gMeasuring ValuesFVC: FVC, FEV 1.0, FEV 1/FVC, FEF 0.2 - 1.2L, FEF 25 - 75%, FEF 75 - 85%, PEF, FEF 25%, FEF 50%, FEF 75%, FIVC, FEV6, PEFT, FET 100%SVC: SVC, ERV, IRV, TV, ECMVV: MVV, FB, TVPresentationFlow volume loopFlow time plotMeasurment values tableMeasuring rangeFlow: 0 to ±14 L/sVolume: 0 to ± 12LMeasuring methodDifferential pressure methodPrediction equationMorris-Polgar, ECCS-Quanjer, Knudson-ITS, Pereira, Korea CJKSample rate200 samples/secFlow impedance
