| Brand | LEESON |
|---|---|
| MPN | 048A17T2002 |
| Model | 048A17T2002 |
| Type | Agricultural Fan Motor |
| California Prop 65 Warning | N |
| Country of Origin | MX |
| NumberOfItems | 1 |
| Restricted States | [] |
| Style | Agricultural Fan Motor |
| Item | Agricultural Fan Motor |
| Overall Length | 10-1/16" |
| Weight | 18.0000 |
| Length | 12.440 |
| Mounting | Base/Stud |
| Width | 9.130 |
| Depth | 9.130 |
| Voltage | 115/230 |
| Features | Farm Duty Motor, Single Phase, Motor Design Permanent Split Capac |
| Bearings | Ball |
| Hz | 60 |
| Phase | 1 |
| Footnotes | Extended Studs |
| Frame Material | Rolled Steel |
| Battery Included | No |
| Duty | Continuous |
| HP | 1/4 |
| Full Load Amps | 2.9/1.4 |
| Motor Type | Split-Phase |
| Number of Speeds | 1 |
| Thermal Protection | Auto |
| Max. Ambient Temp. | 40 Degrees C |
| RPM Range | 1601-1700 |
| Length Less Shaft | 7-1/2" |
| Nameplate RPM | 1625 |
| Rotation | CW/CCW |
| Enclosure | Totally Enclosed Air Over |
| Motor Sub Application | Agricultural Fan |
| Body Dia. | 5-11/16" |
| Frame | 48Z |
| Ins. Class | B |
Check the listing for details. Leeson 048A17t2002 Permanent Split Capacitor General Purpose Farm Duty Motor,. Width: 9.130, Condition: New, Made in MX. Listed at 212.99 USD. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Cradle Base. General Purpose. Agricultural Fan Motor.
