| Shipping notice | Can not ship to Puerto Rico/Alaska/Hawaii |
|---|---|
| Table size | Φ100mm |
| Load | 45kg |
| Itinerary | 360° |
| Packing size | 23*13*16cm |
| Parallelization | 80μm |
| Resolution / Pulse(no subdivision) | 0.01 ° |
| Recoil | 0.005° = 18" |
| Material | Aluminum-black anodized |
| Top board beat | 15μm |
| Transmission mode | worm gear (reduction ratio 1/180) |
| Weight | 1.7kg |
| Guide rail | bearing |
| Product model | HT03RA100 |
| Absolute on-axis accuracy | 0.01° = 36" |
| Repeatability | 0.005° = 18" |
| Rotation speed (maximum) | 25° / sec |
| Gross weight | 2kg |
| Resolution / Pulse(20 subdivisions) | 0.0005° |
| Eccentricity | 10μm |
| Lost movement | 0.005° = 18" |
| Brand | Unbranded |
Check the listing for details. Motorized Rotation Stage Optical Rotary Table Electric Optical Rotation Platform. Condition: New. Listed at 187.32 USD. Specification Material: Aluminum Alloy Color: Black Process: Anodizing, Blackening Style: Modern Mounting Type: Tabletop Table Diameter: 100mm/3.94in Transmission Ratio: 180:1 Drive Mechanism: Worm Gear Structure Guide Rail Form: Bearing Stepper Motor(Step Angle): 42 (1.8 °) Working Current: 1.7A Center Load Capacity: 45kg/99.21lbs Resolution: 0.01 ° (No Subdivision); 0.0005 ° (20 Subdivisions) Max. Speed: 25 °/s Product Size: 18.1*12*4.5cm/7.13*4.72*1.77in Package Size: 27*17.5*10cm/10.63*6.89*3.94in Gross Weight: 1.8kg/3.97lbs Net Weight: 1.71kg/3.77lbs Package Included 1* Electric Rotating Platform .
