Check the listing for details. OMRON E2B-M12KS02-WP-C1 PROXIMITY INDUCTIVE SENSOR SWITCH CYLINDRICAL NEW. Condition: New. Listed at 29.80 USD. Welcome To Fibica If you have any questions, please inform us by eBay message.Close Notes Product Detail Why Daily Mart ? International Shipping Return & Warranty Specification: Size M12 Sensing distance Single Double Type Shielded Unshielded Shielded Unshielded Model E2B-M12[]S02 E2B-M12[]N05 E2B-M12[]S04 E2B-M12[]N08 Sensing distance 2 mm ?10% 5 mm ?10% 4 mm ?10% 8 mm ?10% Setting distance 0 to 1.6 mm 0 to 4 mm 0 to 3.2 mm 0 to 6.4 mm Differential travel 10% max. of sensing distance Detectable object Ferrous metal (The sensing distance decreases with non-ferrous metal.) Standard sensing object (mild steel ST37) 12 ?12 ? 1 mm 15 ?15 ? 1 mm 12 ?12 ? 1 mm 24 ?24 ? 1 mm Response frequency *1 1,500 Hz 800 Hz 1,000 Hz 800 Hz Power supply voltage 10 to 30 VDC. (including 10% ripple (p-p)) Current consumption 10 mA max. Output type -B models: PNP open collector -C models: NPN open collector Control output Load current 200 mA max. (30 VDC max.) Residual voltage 2 V max. (under load current of 200 mA with cable length of 2 m) Indicator Operation indicator (Yellow LED) Operation mode (with sensing object approaching) -B1/-C1 models: NO -B2/-C2 models: NC Protection circuit Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Short-circuit protection Ambient air temperature Operation and storage: -25 to 70°C (with no icing or condensation) Temperature influence ?0% max. of sensing distance at 23°C within temperature range of -10 to 55°C ?5% max. of sensing distance at 23°C within temperature range of -25 to 70°C Ambient humidity Operation and Storage: 35 to 95% Voltage influence ?% max. of sensing distance in 24 VDC ?5% Insulation resistance 50 MO min. (at 500 VDC) between current-carrying parts and case Dielectric strength 1,000 VAC at 50/60 Hz for 1 min between current-carrying parts and case Vibration resistance 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y and Z directions Shock resistance 1,000 m/s2 , 10 times each in X, Y and Z directions Standard and listings (1) IP67 (IEC60529) (2) EMC (EN60947-5-2) Connecting method Pre-wired models (standard is 4 mm dia. PVC cable with length = 2 m, 5 m). Connector models (M12-4pin) Weight (packaged) Pre-wired model Short body: Approx. 75 g, Long body: Approx. 80 g *2 Connector model Short body: Approx. 35 g, Long body: Approx. 40 g Material Case Brass-nickel plated Sensing surface PBT Cable Standard cable is 4 mm dia. PVC. Clamping nut Brass-nickel plated Toothed washer Zinc-plated iron Package Included: 1 x OMRON E2B-M12KS02-WP-C1 PROXIMITY INDUCTIVE SENSOR SWITCH CYLINDRICAL NEW 6 months warranty 60 days money back Life-time support. Our specialists will be with you during shopping and after-sell. Professional advise and any technical problem will be provided. We will respond any question within 24-hour normally. Please allow longer time for weekend. Our logistic team will pack your order safely, make sure the item will be arrived perfectly. And then the parcels will be pass to courier. The total dispatched time will be around 1-2 days. We focus on product quality, rather than packaging and marketing, in order to deliver the finest quality of product at a fraction cost. We believe that you would like to pay for the item cost except unnecessary costs. Our product team will keep the products up-to-date, which can allows you to purchase the latest and valuable products from our stores. We believe our Wide Product Range will be your selection. How should I make my payment ? We accept PayPal. Your payment is protected by Buyer Protection. Items will be shipped within 1-2 working days of payment being made. No mailing payment will be accepted. How long is the delivery time ? Total delivery time is split into two parts: Processing and Shipping Processing time It takes normally 1-3 business days**. We will check your order, confirm your payment, verify your address and arrange your shipment during this period of time. Shipping time In general, the delivery time of each international courier is as below: Economy Shipping:?10-21?business days in normal. EMS:?5-15?business days in normal. **Reminder: Our warehouse do not process orders durning weekend or any United States public holidays. Therefore, please allow another 1-2 business days to process your weekend orders.** Do you ship to my country ? Yes, we do. Actually, we ship to any countries all over the world (As long as your country is on the earth). Do you provide tracking number ? Sure thing. We will upload the tracking number once the item is dispatched. Here is how you can locate the tracking number: Click My eBay at the top of most eBay pages. You may need to sign in. Click the Purchase History link on the left side of the page. You'll see the tracking number under the item title. Other Shipping Policy We don't responsible for any customs tax and similar fees. All shipping charges are not negotiable. Shipping and handling fee includes all packing, warehouse and distribution cost. How many months warranty do you provide ? 3-24 months warranty is provided to our product
